406 - 5HTAB4521W7H61683
Identification Plate Images
Key Information
- Pic Number
- 197
- Specification
- 406
- Serial Number
- 5HTAB4521W7H61683
- Manufacturer
- Heil
- MFG Year
- 1997
Technical Specifications
- MAWP
- 3.3 psi
- Test Pressure
- 5.0 psi
- Temperature Range
- -40 to 200F
- Head Material
- 5454-O
- Shell Material
- 5454-H32
- Weld Material
- 5356
- Total Volume
- 35394 L
- Max Density
- 1.08 kg/L
Component Thickness Details
| Component | Manufactured Thickness (inches) | Minimum Thickness (inches) |
|---|---|---|
| Head | 0.186 | 0.185 |
Compartment Details
| Compartment | Volume (L) | Exposed Surface (sq.m) |
|---|---|---|
| 1 | 12870 | 31.8 |
| 2 | 8139 | 18.2 |
| 3 | 4164 | 8.7 |
| 4 | 10221 | 25.1 |
